OEM-Style Flush Mount Rear-View Backup Camera

$89.00$129.00

This OEM Style Rear-View Backup Camera is designed for a factory style placement and can be integrated to a built-in car monitor or paired with one of the OEM Style Rear-View Mirror LCD Systems.

Clear

Extended Warranty *

Add up to 3 total years of warranty.

Categories: , SKU: FC-Sony-CCD-HD

Description

OEM Style Flush Mount Backup Camera

The FC is designed especially for all vehicle make and models as a factory parking and rear-view assist upgrade. The OEM Style Flush Mount Camera mounts upwards onto the license plate lip. The FC uses a standard size drill bit for mounting and comes with a set of washer, screw and waterproof adhesive tape to secure the camera in place to withstand any weather condition or car wash. Once mounted, the camera is set at a fixed angle pointing down and out at 45 degrees and covers 170 degrees horizontally giving you a full wide angle bumper to bumper view.

OEM Style Flush Mount Camera Systems Compatibility

Model Model Year Interface System
All All All systems with AV connection





OEM Style Flush Mount Camera Features



Features

Vivid Color High Resolution
170° Wide Angle View
Parking Guide Lines (can be turned on/off)
Waterproof Ip68
Shockproof
Simple Installation















Specifications

Specification Terms Product Values
Image Sensor CCD HD Sony
Power Supply DC12V±1V
Power <1W
Effective Pixels 728*582
Resolution (TV Line) 520
Electronic Shutter 1/60, 1/10,000 sec
Lens Angle 170°
Min. Illumination 0.01lux
IP Rating Ip68
S/N Ratio ≥48dB
Video Output 1.0vp-p.75Ω
Current Consumption 30-60mA
Operating Temp. (F) -20~+100
Storage Temp. (F) -40~+120
TV System NTSC/PAL
White Balance Auto



OEM Style Rear-View Backup Camera Package Content

    • 1 x Sony CCD HD Flush Mount Camera
    • 1 x Power Harness
    • 1 x RCA Extension Cable (Power Extension Lead Built In)
    • 1 x Set (Washer, Screw, Waterproof Adhesive Tape)
    • 1 x User Guide



Additional information

Weight 9 lbs
Dimensions 5 × 3 × 2.5 in
