Buick Regal OEM Integrated Backup Camera System

$450.00

This OEM Integrated Buick Regal  Rear-View Camera System fits all 2013-2018 Regal models with either the 7″ or 8″ IntelliLink. This system includes everything needed to have it installed and ready for use without any dealer activation or coding required.

50 in stock (can be backordered)

Vehicle Year & Screen Size *

Select your vehicle command system.

Camera Option *

Choose which backup camera you’d like for your vehicle.

Front Camera Add-On

Add a front camera that will directly plug onto the system.

Extended Warranty

Add up to 3 total years of warranty.

Extended Warranty *

Add up to 3 total years of warranty.

Category: SKU: FC-MYLCAM/GMIO56-Regal

Description

Buick Regal OEM Integrated Backup Camera System



The FC-MYLCAM/GMIO56 OEM Integrated Backup Camera System is a comprehensive high definition backup camera system for your Buick Regal. Our Sony CCD HD Flush Mount Camera is mounted upwards onto your license plate lip and encased in a waterproof casing. Our MYLCAM/GMIO56 Interface Module is designed to directly connect onto the back of your OEM screen and once installed, will automatically trigger when in reverse displaying a high resolution image of what’s behind you for safety. Our FC-MYLCAM/GMIO56 system is designed to utilize your already existing screen for seamless backup camera integration and will function just like a factory installed backup camera system without the factory installed price.



Buick Regal Systems Compatibility



BUICK Model   Model Year   Multimedia System
Regal

Regal

2013

2014-2018

with 7” IntelliLink

with 8” IntelliLink











Buick Regal Factory Integrated Features



MYLCAM/GMIO56 Features

    • Factory Buick Connect T-Harness
    • Plug & Play Configuration
    • Quick Connect to Video Cable and Rear Camera
    • Auto Trigger when in Reverse
    • Rear Camera Input (RCA)
    • Parking Guide Line Option (ON/OFF)





Buick Regal Backup Camera Features



Features

    • Sony CCD HD Flush Mount Camera
    • Vivid Color High Resolution
    • 170° Wide Angle View
    • Parking Guide Lines (can be turned on/off)
    • Waterproof Ip68
    • Shockproof
    • Simple Installation



Specifications

Specification Terms Product Values
Image Sensor CCD HD Sony
Power Supply DC12V±1V
Power <1W
Effective Pixels 728*582
Resolution (TV Line) 520
Electronic Shutter 1/60, 1/10,000 sec
Lens Angle 170°
Min. Illumination 0.01lux
IP Rating Ip68
S/N Ratio ≥48dB
Video Output 1.0vp-p.75Ω
Current Consumption 30-60mA
Operating Temp. (F) -20~+100
Storage Temp. (F) -40~+120
TV System NTSC/PAL
White Balance Auto











Buick Regal OEM Integrated Backup Camera System Package Content

    • MYLCAM/GMIO56 Video Interface Module
    • Buick Factory Connect T-Harness Set
    • RCA Harness
    • Sony CCD HD Flush Mount Camera
    • Camera Power Harness
    • RCA Extension Cable
    • Camera Washer, Screw & Adhesive Tape
    • Installation Instructions

Additional information

Weight 3.0000 lbs
Dimensions 12 × 8 × 6 in
Year

Make

Model

Vehicle Year & Radio

,

Camera Option

,

Front Camera Add On

,

Extended Warranty

, ,

Make Model Year
Make Model Year
Buick Regal 2013 - 2019
