BENTLEY CONTINENTAL OEM Integrated Backup Camera System

$420.00$529.00

This OEM Integrated BENTLEY Rear-View Camera kit fits all 2004-2010 CONTINENTAL models. The comprehensive Multimedia Video Interface integrates through simple plug-in connection to enable the viewing of external video sources such as Backup Camera (provided in kit), DVD player, TV tuner, Video Game Console, Smartphone, and optional Navigation on your factory built-in car monitor.

Clear

Extended Warranty *

Add up to 3 total years of warranty.

Category: SKU: FC-PHEATON

Description

Bentley Continental OEM Integrated Backup Camera System

The FC-PHEATON systems package is a high definition rear view camera and video integration module for your Bentley. The OEM Integrated backup camera mounts upwards onto the license plate lip and once connected to the video interface module, the image appears automatically in high definition when the vehicle is placed into reverse. The FC-PHEATON Interface Module has a dedicated rear view camera input and (3) additional video inputs should you decide to add a front camera or any external video source using an RCA cable. This system is a simple OEM integration package that maintains your factory set up while upgrading your vehicle with backup camera.

Bentley Continental System Compatibility

BENTLEY Model   Model Year   Multimedia System
Continental GT 2004-2010 Display
Continental GT Speed 2004-2010 Display
Continental Flying Spur 2004-2010 Display
Continental Flying Spur Speed 2004-2010 Display

Bentley Continental Interface Module Features



Input

    • Installation by Plug & Play LVDS Cable
    • 1 x Dedicated Rear-View Camera input
    • 3 x Video Inputs
    • 1 x LCD input



Output

    • 2 x CVBS output (video out for headrest monitor installation)
    • Remote Control & Toggle Switch



Power

    • Input power : 8V DC – 24V DC
    • Consumption : 5W, Max



Board dimension

    • 130mm x 105mm x 22mm

Bentley Continental Backup Camera Features



Features

    • OEM Style Backup Camera
    • SONY CCD HD
    • Vivid Color High Resolution
    • 170° Wide Angle View
    • Parking Guide Lines Option (ON / OFF)
    • Waterproof Ip68
    • Shockproof
    • Simple Installation



Specifications

Specification Terms Product Values
Image Sensor CCD HD Sony
Power Supply DC12V±1V
Power <1W
Effective Pixels 728*582
Resolution (TV Line) 520
Electronic Shutter 1/60, 1/10,000 sec
Lens Angle 170°
Min. Illumination 0.01lux
IP Rating Ip68
S/N Ratio ≥48dB
Video Output 1.0vp-p.75Ω
Current Consumption 30-60mA
Operating Temp. (F) -20~+100
Storage Temp. (F) -40~+120
TV System NTSC/PAL
White Balance Auto





Bentley Continental OEM Integrated Backup Camera System Package Content



    • Bentley Video Interface Module
    • Remote Control
    • IR Cable
    • Mode Cable (Toggle Switch)
    • Power Cable with Protective Filter
    • LCD Out Cable
    • AV Harness
    • OEM Style Flush Mount Backup Camera (Sony CCD HD)
    • 30 Ft. RCA Extension Cable (Extension Power Leads)
    • Camera Power/Ground Harness
    • Camera Washer & Screw Set
    • Waterproof Adhesive Tape
    • Installation Instructions

Additional information

Weight 30 lbs
Dimensions 12 × 8 × 6 in
